How NAT uses state, and why it breaks assumptions

17 min read 3 outcomes Scenario quiz

By the end of this module you will be able to:

  • Explain what NAT changes, why it requires state, and how return traffic is matched
  • Describe the end-to-end principle and how NAT breaks it
  • Explain NAT traversal techniques (STUN, TURN, ICE) and why peer-to-peer applications need them

Real-world problem · Ongoing

Carrier-grade NAT: when your ISP gives you a shared IP address you cannot control

Carrier-grade NAT (CGN or CGNAT) is NAT performed by an Internet Service Provider (ISP) or mobile carrier rather than a home router. The ISP assigns a single public IP address to multiple customers simultaneously. All traffic from those customers reaches the internet from the same source IP, with different port numbers distinguishing each customer's connections.

RFC 6888 documents the requirements and implications of CGNAT. The practical consequences for developers include broken IP geolocation (the source IP is the ISP's NAT device in a data centre, not the customer's location), broken rate limiting by IP (one IP serves thousands of customers), and broken services that assume a persistent 1:1 mapping between user and IP address.

For end users, CGNAT makes inbound connections impossible, breaks certain gaming services, and can make port forwarding unavailable. IPv6 addresses this problem by providing enough addresses for every device to have its own public address, removing the need for NAT entirely. But IPv4 CGNAT is standard on most mobile networks and many residential broadband connections globally.

A developer reports that their application's IP geolocation feature shows wrong results for customers on certain mobile carriers. All those customers show the same IP address, and it is located in a data centre, not their city. What is happening?

NAT is stateful translation, not universal reachability

Inbound traffic without a matching state entry or explicit rule has nowhere safe to go.

Two peers behind NAT need help: STUN, then TURN, chosen by ICE Three stacked rows escalate through the NAT-traversal options. Row 1 STEP 1 Direct attempt fails: both peers send dashed arrows toward each other's private addresses; outcome BLOCKED. Row 2 (emphasis) STEP 2 STUN discovers reflexive address, peers hole-punch: each peer queries a public STUN server which returns its NAT mapping, then a brand-red emphasis arrow shows data flowing peer-to-peer; outcome PATH OK. Row 3 STEP 3 Symmetric NAT blocks; TURN relays: traffic flows through a public TURN server in both directions; outcome PATH OK. STEP 1 Direct attempt fails PROTOCOL no STUN, no TURN Peer A NAT_A 10.0.0.5 Peer B NAT_B 10.0.0.5 SYN to peer B's address? no route to peer A's address BLOCKED Each peer's address is private; neither can target the other. STEP 2 STUN discovers reflexive address, peers hole-pun ch PROTOCOL RFC 5389 + ICE candidates Peer A NAT_A 10.0.0.5 Peer B NAT_B 10.0.0.5 STUN public server request you look like NAT_A:62000 request you look like NAT_B:62100 data via NAT public mapping PATH OK STUN reveals the public mapping; if both NATs are endpoint-independent, hole STEP 3 Symmetric NAT blocks; TU RN relays PROTOCOL RFC 8656 Peer A NAT_A 10.0.0.5 Peer B NAT_B 10.0.0.5 TURN RFC 8656 relay send to relay forward to peer B reply via relay forward to peer A PATH OK All traffic relays through a public server. Works everywhere; costs bandwidt built by ransfordsnotes.com

Two peers behind NAT cannot connect by guessing each other's address. STUN reveals the reflexive address, hole-punching opens the path, TURN relays when nothing else works, ICE chooses.

13.1 Why NAT exists: the IPv4 address exhaustion problem

IPv4 uses 32-bit addresses, providing approximately 4.3 billion unique addresses. That sounded sufficient in 1981. By the early 1990s, it was clear it would not be enough for the growing internet. NAT (Network Address Translation) was one solution: allow many devices to share a single public IP address.

RFC 3022 defines traditional NAT. The idea is straightforward. An organisation with one public IP address can have hundreds of internal devices using private address ranges (10.0.0.0/8, 172.16.0.0/12, 192.168.0.0/16 as defined in RFC 1918). The NAT device rewrites source addresses on outgoing packets and reverses the process for incoming traffic.

The rewriting creates an obligation: the NAT device must track every active translation so it knows where to send the return traffic. This is the state requirement. NAT is not stateless translation. It is translation plus a per-connection mapping table.

The mechanism that supports many-to-one sharing comes in several forms depending on the direction of traffic and how ports are managed.

13.2 SNAT, DNAT, and port address translation

SNAT (Source NAT) rewrites the source address of outgoing packets. A device at 192.168.1.5 sends a packet; the NAT device rewrites the source to 203.0.113.1 (the public IP) before forwarding it. Return traffic to 203.0.113.1 is rewritten back to 192.168.1.5.

DNAT (Destination NAT) rewrites the destination address of incoming packets. Traffic arriving for 203.0.113.1:80 is rewritten to 192.168.1.10:80 to reach a web server on the internal network. Port forwarding is DNAT. Load balancers often use DNAT to distribute traffic across backend servers.

PAT (Port Address Translation), also called NAPT (Network Address Port Translation), allows many internal addresses to share one public IP by using different source port numbers to distinguish connections. This is what home routers do. Device A at 192.168.1.2 and Device B at 192.168.1.3 both reach the internet from the same public IP, but their connections use different source port numbers so the NAT device can tell return traffic apart.

Traditional NAT allows hosts within a private network to transparently access hosts in the external network, in most cases. In traditional NAT, sessions are uni-directional, outbound from the private network.

RFC 3022 - Section 4, Traditional NAT

The phrase 'uni-directional, outbound' is the key limitation. Traditional NAT creates mappings on demand when an internal device initiates a connection. Unsolicited inbound connections have no mapping to follow. This is why a home device behind NAT cannot receive inbound connections unless port forwarding is configured.

PAT works because the NAT owns a state table

Internal tuple, translated tuple, remote tuple, and timeout must match for return traffic to find the original host.

PAT shares one public IP across many inside hosts via the mapping table Three inside-host cards on the left (Laptop emphasised, Phone, TV) connect through a gateway labelled PAT engine with public IP 198.51.100.7. To the right of the gateway is the NAT mapping table with five columns INSIDE, TRANSLATED, DESTINATION, PROTO, TIMER. Three rows show that Laptop and Phone both happen to use source port 53144 internally but the gateway translates them to different public source ports 62000 and 62001. Arrows connect each host through the gateway to its corresponding table row. Laptop 192.168.1.12 src 53144 Phone 192.168.1.20 src 53144 TV 192.168.1.30 src 49200 GATEWAY PAT engine public IP 198.51.100.7 INSIDE TRANSLATED DESTINATION PROTO TIMER 192.168.1.12 :53144 198.51.100.7 :62000 203.0.113.40 :443 TCP 300 s 192.168.1.20 :53144 198.51.100.7 :62001 203.0.113.40 :443 TCP 300 s 192.168.1.30 :49200 198.51.100.7 :62002 146.75.16.4 :443 TCP 299 s built by ransfordsnotes.com

PAT works because the gateway remembers which translated port belongs to which internal host:port. Without that state table, return traffic has nowhere to go.

All three NAT forms require the same underlying mechanism: a state table that records active mappings and matches return traffic to the correct internal host.

13.3 The NAT state table

For every active connection through the NAT device, a table entry records the original source IP and port, the translated source IP and port, and the destination IP and port. Return traffic is matched against this table: incoming packets with a destination matching a translated entry are rewritten back to the original source.

Each entry has a timer. When no matching traffic is seen for the timeout period, the entry is removed. The timeout varies by protocol. TCP connections have longer timeouts than UDP flows. This creates intermittent failures: a long-lived TCP connection that is idle for longer than the NAT timeout will have its state entry removed. When the connection becomes active again, return traffic has no entry to match and is dropped.

This is why applications that maintain long-lived idle connections, such as SSH sessions, sometimes drop silently after a period of inactivity. The connection appears open on both ends but the NAT state has expired. TCP keepalives or application-level heartbeats prevent this by sending periodic small packets to refresh the NAT entry.

When NAT state expires, the return path disappears

Long idle flows fail because the middlebox forgets the mapping before the endpoints do.

When the NAT timer expires, return packets are silently dropped A five-phase timeline shows what happens to a long-idle NAT entry. Phase 1 (t=0s) SYN sent: client opens TCP, gateway creates entry. Phase 2 (t=0-60s) active: data flows, timer refreshes. Phase 3 (t=60-600s) idle: no traffic, timer counts down silently. Phase 4 (t>600s, emphasis) expired: client still thinks the connection is open, but the gateway removed the entry. Phase 5 (t>600s+1, emphasis) reply arrives but has no matching state and is dropped. Below the phases, a coloured state bar shows NAT ENTRY transitioning CREATED, ACTIVE, IDLE, then EXPIRED and DROPPED in dashed outline. A timer indicator counts down underneath each phase. A footer suggests the keep-alive fix. T = 0 S SYN sent CLIENT client opens TCP GATEWAY creates table entry T = 0 TO 60 S Connection active CLIENT data flows in both dir ections GATEWAY timer refreshes on eve ry packet T = 60 TO 600 S Connection idle CLIENT no application traffic GATEWAY timer counts down sile ntly T > 600 S Entry expired CLIENT client still thinks it is open GATEWAY entry removed from tab le T > 600 S + 1 Reply arrives CLIENT server sends data GATEWAY no matching state, pac ket dropped NAT ENTRY CREATED NAT ENTRY ACTIVE NAT ENTRY IDLE NAT ENTRY EXPIRED NAT ENTRY DROPPED TIMER timer 100% timer 78% timer 56% timer 34% timer 12% Fix: send a keep-alive (TCP keepalive, SSH ServerAliveInterval, application heartbeat) inside the gateway's idle window. built by ransfordsnotes.com

A NAT entry has a timer. When the connection goes idle past the timeout, the entry is removed. The next reply packet matches nothing and is silently dropped.

The state table solves the return-traffic problem, but the statefulness also creates a deeper architectural shift in what devices can do.

13.4 How NAT breaks the end-to-end principle

The end-to-end principle (described in the original internet architecture work by Saltzer, Reed, and Clark in 1984) holds that intelligence should be placed at the endpoints of a network, not in the middle. Each device should be directly addressable and reachable. The network should move packets, not make decisions about them.

NAT violates this. An internal device's address is not globally routable. It cannot receive unsolicited connections. Two devices behind different NATs cannot directly communicate without one initiating to the other's public address, or without a third-party relay.

Peer-to-peer applications (video calls, file sharing, gaming) break under NAT because both peers may be behind NAT and neither can directly receive a connection from the other. This is the NAT traversal problem.

That architectural limitation has spawned a whole set of traversal techniques that applications use to establish peer connectivity despite NAT being in the way.

13.5 NAT traversal: STUN, TURN, and ICE

STUN (Session Traversal Utilities for NAT), defined in RFC 5389, is a protocol that allows a client to discover its public IP address and port as seen from outside its NAT. The client sends a request to a public STUN server; the response tells the client what source IP and port the server observed. The client can then share this "reflexive" address with peers.

TURN (Traversal Using Relays around NAT) is a fallback when direct connection is impossible. When both peers are behind NATs that block hole-punching, a TURN server relays all traffic between them. TURN works in every NAT configuration but adds latency and bandwidth cost.

ICE (Interactive Connectivity Establishment), defined in RFC 8445, is the framework that coordinates candidate gathering and connectivity checks. An ICE agent gathers multiple candidate addresses (local, STUN-discovered, TURN relay), shares them with the peer, then tests each pair to find the best working path. WebRTC, which powers most web-based video calling, uses ICE.

Common misconception

NAT is a security feature.

NAT restricts unsolicited inbound connections as a side effect of its stateful translation design, not as a deliberate security mechanism. It provides no authentication, no access control, and no filtering of connection content. A firewall with a deny-inbound policy provides the same reachability restriction while also applying explicit security policy. Relying on NAT as your primary security boundary is a design error.

13.6 Check your understanding

Two devices behind the same NAT both connect to the same web server on port 443. How does the NAT device distinguish the return traffic?

An SSH session to a remote server stops responding after 30 minutes of inactivity. The connection appears still open on both sides. What is the most likely cause?

Core distinctions

  • NAT rewrites IP addresses (and ports in PAT) in packets and maintains a state table to match return traffic. State entries expire when idle.
  • SNAT rewrites source addresses on outbound traffic. DNAT rewrites destination addresses for inbound traffic. PAT allows many devices to share one IP using different port numbers.
  • NAT breaks the end-to-end principle. Internal devices cannot receive unsolicited inbound connections. Peer-to-peer applications require NAT traversal techniques (STUN, TURN, ICE).
  • NAT is not a security feature. It restricts inbound reachability as a side effect of stateful translation, not through explicit access control policy.

Standards and sources cited in this module

  1. RFC 3022, Traditional IP Network Address Translator (Traditional NAT)

    Section 2, Terminology; Section 4, Traditional NAT

    Defines traditional NAT types and the stateful mapping requirement. Quoted in Section 13.2 for the uni-directional session design.

  2. RFC 5389, Session Traversal Utilities for NAT (STUN)

    Section 1, Introduction; Section 5, Definitions

    Defines STUN and the reflexive address discovery mechanism. Referenced in Section 13.5 for the NAT traversal description.

  3. RFC 6888, Common Requirements for Carrier-Grade NATs (CGNs)

    Section 3, Requirements; Section 4, Logging Requirements

    Defines CGNAT requirements and documents operational problems. Used in the opening case study for the geolocation and rate limiting consequences.

  4. RFC 8445, Interactive Connectivity Establishment (ICE)

    Section 2, Overview; Section 5, Gathering Candidates

    Defines the ICE framework used in WebRTC. Referenced in Section 13.5 for the candidate gathering and connectivity check description.

NAT handles addressing at the edge. Module 14 covers what protects the data itself: TLS encryption, certificate chain validation, forward secrecy, and the common errors you will encounter when something in the trust chain breaks.
