Applied capstone
By the end of this module you will be able to:
- Apply STRIDE and attack tree analysis to a real system architecture
- Identify OWASP Top 10 and API Security Top 10 issues in a described codebase
- Recommend identity and access control improvements for a given context
- Propose a logging and detection plan with specific event types and Sigma rule patterns
Scenario: FinPay API architecture
FinPay's current architecture: Node.js API deployed on AWS EC2 behind an Application Load Balancer; PostgreSQL on Amazon RDS containing customer PII, payment card tokens, and transaction records; API keys issued per merchant, passed as a query string parameter; React single-page application served from S3 via CloudFront; manual deployments via SSH directly to EC2 with no CI/CD pipeline; application logs written to the EC2 instance's local disk, not forwarded to any central store.
The six researcher findings are: (1) API key visible in browser network tab and server logs via URL query parameter; (2) merchant_id in a transaction query can be changed to retrieve another merchant's history; (3) full card tokens returned in all transaction responses even when not needed; (4) SQL injection via search filter returning a database error with a partial SQL query; (5) refund endpoint accepting any refund_amount with no server-side maximum, tested with 10,000x the original transaction amount; (6) API accepts plain HTTP connections on port 80.
With an understanding of scenario: finpay api architecture in place, the discussion can now turn to part 1: stride classification and owasp mapping, which builds directly on these foundations.
Part 1: STRIDE classification and OWASP mapping
Applying STRIDE and OWASP Top 10 / API Security Top 10 to each finding:
- Finding 1 (API key in URL): STRIDE: Information Disclosure (the credential is exposed in logs and history). OWASP: A07:2021 Identification and Authentication Failures. Mitigation: move the key to the Authorization request header; rotate the exposed keys immediately.
- Finding 2 (merchant_id enumeration): STRIDE: Elevation of Privilege (accessing resources beyond authorisation scope). OWASP: A01:2021 Broken Access Control and API1:2023 BOLA. Mitigation: server-side check that the authenticated merchant's ID matches the requested merchant_id before returning data.
- Finding 3 (card tokens in all responses): STRIDE: Information Disclosure. OWASP: API3:2023 Broken Object Property Level Authorisation. Mitigation: define explicit response schemas per endpoint; return card tokens only when the caller explicitly needs them and has the required scope.
- Finding 4 (SQL injection): STRIDE: Tampering (data integrity compromised) and Information Disclosure. OWASP: A03:2021 Injection. Mitigation: parameterised queries or prepared statements for all database interactions.
- Finding 5 (unlimited refund amount): STRIDE: Tampering (financial integrity). OWASP: API4:2023 Unrestricted Resource Consumption (business logic abuse variant). Mitigation: server-side maximum validation that the refund amount does not exceed the original transaction amount.
- Finding 6 (plain HTTP accepted): STRIDE: Information Disclosure (card tokens and API keys transmitted in cleartext). OWASP: A02:2021 Cryptographic Failures. PCI DSS: Requirement 4.2.1 (TLS required for cardholder data in transit). Mitigation: redirect all HTTP to HTTPS at the load balancer; enforce TLS 1.2 minimum.
With an understanding of part 1: stride classification and owasp mapping in place, the discussion can now turn to part 2: identity and verification remediation, which builds directly on these foundations.
Part 2: Identity and verification remediation
API authentication weaknesses (Finding 1): (a) Query string transmission exposes the key in server logs, browser history, and referrer headers. Fix: transmit in the Authorization header. (b) One key grants all operations with no scope restriction. Fix: scope keys per operation type (read, write, refund), using OAuth 2.0 Client Credentials flow with named scopes per RFC 6749 Section 4.4. (c) For a financial API processing four million pounds daily, a static API key is a weak authentication method. Fix: migrate server-to-server integrations to OAuth 2.0 Client Credentials with short-lived access tokens, or to mTLS for the highest-assurance integrations.
Merchant portal (React SPA): The portal should use Authorization Code with PKCE (RFC 7636) for user-delegated access. The Implicit flow is deprecated in RFC 9700 because access tokens appear in URL fragments accessible to browser history and referrer headers.
Minimum-viable DevSecOps pipeline: At pull request: Semgrep with an injection ruleset blocks SQL concatenation patterns before merge. At dependency update: Snyk or Dependabot alerts on critical CVEs in package.json. At build: SBOM generation (cdxgen or Syft) produces a CycloneDX SBOM stored alongside the artefact. Before deployment to staging: OWASP ZAP active scan against the staging environment, failing on any HIGH finding. At release: SAST quality gate enforcement.
With an understanding of part 2: identity and verification remediation in place, the discussion can now turn to part 3: logging and detection plan, which builds directly on these foundations.
“A denial of service or loss of availability is typically the most visible security failure, but breaches of confidentiality and integrity are often more damaging to organisations and individuals in the long term.”
NIST SP 800-218 (SSDF), Section 2: Practice Group RV (Respond to Vulnerabilities)
“Security assessment activities should be planned and coordinated to minimise disruption to normal business operations while still providing adequate confidence in the security posture of the system.”
NIST SP 800-115: Technical Guide to Information Security Testing and Assessment, Section 2.1 (2008)
Part 3: Logging and detection plan
Current logging (console.log to local disk) does not capture: (1) authorisation failures per object (each instance of Finding 2 exploitation leaves no trace); (2) SQL error events with query context (Finding 4 generates database errors not forwarded to any central store); (3) refund amount anomalies (Finding 5 leaves no structured record).
Minimum log events for the FinPay scenario: (1) authentication.success and authentication.failure with source_ip, merchant_id, and timestamp; (2) api.access events including authenticated_merchant_id, resource_owner_id (the merchant_id in the request), endpoint, and response_status; (3) data.export events for card token returns including requesting_merchant_id and record_count; (4) database.error events with a sanitised error code (not the raw SQL error).
Detection rule for Finding 2 (BOLA enumeration): Sigma condition that counts distinct resource_owner_id values grouped by authenticated_merchant_id over a five-minute timeframe; alert if the count exceeds ten. This would have detected the T-Mobile-style enumeration within minutes rather than weeks.
PCI DSS compliance gaps: Finding 4 (SQL injection in a system containing cardholder data) directly violates Requirement 6.2.4 (protection against injection attacks). Finding 6 (plain HTTP) violates Requirement 4.2.1 (TLS for cardholder data in transit). Evidence required at audit: proof of parameterised queries in the codebase, SAST results showing no injection findings, and load balancer configuration showing HTTP redirect to HTTPS.
Common misconception
“A single insecure design flaw can be categorised under only one OWASP category.”
Finding 2 in the FinPay scenario maps to both A01:2021 Broken Access Control and API1:2023 BOLA simultaneously. Finding 4 (SQL injection in a system containing card data) maps to A03:2021 Injection, A09:2021 Security Logging Failures (the error is not logged), and directly violates PCI DSS Requirement 6.2.4. Real security findings typically fail multiple controls across multiple frameworks at once.
Common misconception
“A penetration test that finds no critical vulnerabilities proves the application is secure.”
A penetration test is a point-in-time assessment. It reflects the security posture at the moment of testing against a specific scope with specific testers using specific techniques in a defined timeframe. Applications change continuously: new code deployed the day after a pentest may introduce a CVSS 10.0 vulnerability. A more useful framing is that a clean pentest provides confidence in the security of the tested scope at the tested point in time. Continuous security through automated SAST/DAST in the CI/CD pipeline, combined with annual pentests, provides significantly higher assurance than annual pentests alone.
Key takeaways
- A single insecure API design can simultaneously fail across multiple OWASP categories: the FinPay scenario exhibits BOLA, injection, excessive data exposure, missing business logic validation, and cryptographic failures simultaneously.
- Identity controls, verification pipelines, and logging are interdependent: without structured logs you cannot detect BOLA exploitation; without a CI/CD pipeline you cannot gate on injection vulnerabilities; without strong authentication there is nothing for access control to verify against.
- The shift from manual deployment to an automated gated pipeline is one of the highest-use security improvements for an early-stage engineering team. A pull-request SAST gate would have caught Finding 4 before it ever reached production.
- PCI DSS and security best practice usually align: fixing the FinPay security issues would simultaneously address the PCI DSS Requirement 4.2.1 (TLS) and Requirement 6.2.4 (injection protection) compliance gaps.
You have completed the Applied stage. You can threat model, secure identity flows, harden web applications and APIs, gate releases, and detect incidents. The Practice and Strategy stage scales these skills to organisational programmes: secure SDLC, zero trust architecture, cloud security, supply chain risk, and incident response at enterprise scale. The first module is Secure software development lifecycle.
Standards and sources cited in this module
Web application vulnerability classification covering A01-A10 referenced in the FinPay analysis.
OWASP API Security Top 10 2023
API vulnerability classification covering BOLA, resource consumption, and property-level authorisation.
NIST SP 800-218: Secure Software Development Framework (SSDF)
Secure software development practices: produce well-secured software, respond to vulnerabilities.
Payment Card Industry Data Security Standard: Requirements 4.2.1 (TLS) and 6.2.4 (injection protection).
